Features of this set of equipment:
1, stepper motor control feeding speed, speed adjustable, shorten the feeding time, improve acouracy and eficiency.
2, touch screen control panel, outing length and processing quantity can be directly input into the control system, cuting length is controled by the controller, automatic positioning.
3. Strong continuity of equipment operation and compact production rhythm.
4. There is water cooling device inside the auting gun to ensure that the cuting gun can be cooled in time.
5. mature smoke exthaust dust removal system, the surrounding environment is purfed.
| Name | Description | Composition | Technical Parameters |
| Plasma automatic pipe cutting machine | The plasma tube cutting machine uses a plasma cutting machine as a cutting tool. Compared with the traditional machined tube cutting machine, it has the advantages of fast speed and no cutting force. When working, the tube rotates, and the plasma cutting head cuts the tube. After one round of cutting, the cutting head automatically lifts up; the tube automatically moves forward according to the set length to proceed to the next cutting process. | The plasma cutting machine is mainly composed of a cutting machine, a cutting cantilever mechanism, a bed, a material discharging rack, a feeding and clamping trolley, an electronic control system, a dust removal system, a material supporting trolley, etc. | Cutting thickness: 3~12mm Cutting efficiency: 10 seconds/piece (φ325*6m thick steel pipe, excluding loading and unloading) Feeding speed: 10~780mm/min Spindle speed: 0~40r/min Dust removal fan power: 7.5KW Air volume: 5000~10000m³/h Total equipment power: 72kW |
