Keywords：Sand blasting machine for inner wall of steel pipe
Category： Products
Whatsapp：8619053621740
Email：admin@meilijixie.com.cn
| Name | Description | Composition | Technical Parameters |
| Shot-peening cleaner for inner wall of steel pipe |
The steel pipe inner wall shot blasting machine is a special steel pipe shot blasting equipment independently developed by our company. Through shot blasting, not only can the oil, rust, scale and other impurities on the inner surface of the steel pipe be removed, but also the internal residual stress of the steel pipe can be eliminated, the fatigue strength of the steel pipe can be improved, the roughness value and hardness can be achieved, the fatigue strength of the steel pipe can be improved, the roughness value and hardness can be achieved, the inner surface and internal quality of the steel pipe can be improved, and finally the purpose of anti-corrosion, pipe protection and extending the service life of the workpiece can be achieved. | The steel pipe inner wall shot blasting cleaning machine consists of a shot recovery chamber, a shot blaster, an elevator, a separator, a screw conveyor, a shot control system, an automatic feeding system, a hosting bracket, a spray gun rotation device, a dust removal system, an electronic control system and other parts. | Workpiece diameter: Φ100~Φ1000 mm Workpiece length: 4000~6000mm Number of spray guns: 3 Air consumption/Φ10 nozzle: 18.9m³/min Equipment power: ~25kW |
| Steel tube inner wall shot blasting machine |
The inner wall shot blasting machine of steel pipe is suitable for the shot blasting treatment of the inner surface of steel pipe and steel pipe products, removing the oxide layer and welding slag and other debris, showing the metallic luster, which is conducive to the painting and coating of the workpiece. The inner wall shot blasting machine of steel pipe can select different blades according to the different diameters of steel pipes, and the shot blasting cleaning is driven by a hydraulic motor. | The steel pipe inner wall shot blasting machine is mainly composed of front and rear movable sealing chambers, left and right inner wall hydraulic movable shot blasting machines, belt conveyor type shot conveying mechanism, bottom belt conveyor, elevator, maintenance platform, separator, dust removal system, inner wall shot blasting machine walking mechanism, steel pipe upper and lower unloading mechanism, hydraulic system and electronic control system. | Workpiece diameter: 800~Φ1800 mm Workpiece length: 12000mm Production cycle: 30min/piece (Φ1800) Transmission mode: hydraulic motor drive |
